The BEA LZR-H100 laser safety scanner offers a real alternative to induction loops: time gain during installation, detection of all types of vehicles and greater adaptability. This laser sensor for rising barriers is used to open, secure and/or detect a presence. It offers great flexibility in defining the width and depth of the detection zones (max detection field of 9.9 m x 9.9 m). Specifications: Technology: laser scanner, Time-Of-Flight measurement (4 laser curtains) Detection Mode: Motion & Presence Max. Detection range: 9.9m x 9.9m Remission Factor: >2% Angular Resoltuion: 0.3516 Emission Characteristics: IR laser: Wavelength 905nm; max. Output pulse power 75w (Class 1) Visible laser: wavelength 650nm; max. output CW 3mW (Class 2) Supply Voltage: 10 – 35V DC @ sensor side Power consumption: < 5 W Peak Current at Power-On 1.8A (Max. 80ms @ 35V) Cable length: 5m (standard) Max. 10m Dimensions: 125mm (D) x 93mm (W) x 70mm (H) (With mounting bracket 14mm) Mounting Angles on bracket: -45 degrees to 45 degrees Rotation Angles on Bracket: -5 degrees to 5 degrees lockable Tilt angles on bracket: -3 degrees to 3 degrees IP65 Rated
